800mm Silt Gravel Clay Ground Drill Bit Cut Diameter Application Earth Screw Auger

Brand Name : APIE

Model Number : K4-1

Certification : CE and ISO9001

Place of Origin : Jiangsu, China

MOQ : 1 sets

Price : $1100+

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 15 sets/month

Delivery Time : 10-15days

Packaging Details : nude packing

Product name : straight auger

Drilling diameter : 600-3000 mm or as required

Color : Black or as required

Application : silt, gravel, clay and highly decomposed rock

Teeth Type : Soil teeth

Type : Drilling auger

Kelly Box : 130*130 ,150*150,200*200

Material : Steel GB-Q345B

Contact Now

800mm Cut Diameter Application: Silt, Gravel, Clay Ground Drill with Earth Screw Auger Drill Bit



Product Feature

1. Fish-tail Pilot for Accurate Positioning: Our drill bit is equipped with a fish-tail pilot that ensures precise positioning during drilling operations. This feature enhances the accuracy and effectiveness of the drilling process.

2. Hard Facing Strips on Flights for Wear Protection: The flights of our drill bit are reinforced with hard-facing strips, providing excellent wear protection. This ensures the longevity and durability of the drill bit, even when used in challenging soil conditions.

3. Kelly Box: 130mm, 150mm, 200mm (Optional): Our drill bit is compatible with different sizes of kelly boxes, including 130mm, 150mm, and 200mm. This versatility allows for easy integration with various drilling equipment, providing flexibility and convenience.

4. Single Cut Soil Auger and Double Cut Soil Auger Available: We offer both single cut and double cut soil auger options to cater to different drilling requirements. Whether you need efficient soil removal with a single cut or enhanced drilling performance with a double cut, our drill bit can meet your specific needs.



Choose our 800mm cut diameter drill bit for silt, gravel, and clay ground applications. Benefit from its advanced features, including the fish-tail pilot, hard facing strips, and compatibility with different kelly box sizes.


Product Description
1.Augers have been designed for drilling in dry soil and in rock.
2.Various teeth configurations are available for different soil conditions. The geometry of the teeth arrangement is optimized for reaching excellent cutting performance.
3.For large drilling diameters or for the use in uncased bores, augers with double start head are recommended.

Cutting
Dia.		 Spiral
HIT.		 Spiral
Pitch		 Shell
THK.		 Spiral
OD.		 Center
Tube
OD.		 Teeth
No.		 Weight
φ600 1000 400 30+20 550 219 5 535
φ800 1500 600 30+20 750 219 6 750
φ900 1500 600 30+20 850 219 7 820
φ1000 1500 600 30+20 950 219 9 950
φ1200 1500 600 30+30 1150 219 11 1050
φ1500 1500 600 30+30 1450 273 13 1450
φ1600 1500 600 30+30 1550 273 15 1650
φ1800 1500 600 30+30 1750 273 17 1950
φ2000 1500 600 40+40 1950 273 19 2300
φ3000 1500 600 40+40 2950 325 29 4550



Product Details



800mm Silt Gravel Clay Ground Drill Bit Cut Diameter Application Earth Screw Auger

800mm Silt Gravel Clay Ground Drill Bit Cut Diameter Application Earth Screw Auger

800mm Silt Gravel Clay Ground Drill Bit Cut Diameter Application Earth Screw Auger



FAQ

1: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment



2: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm, drilling tools



3: What's your service ?

We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
